A cool and clear evening with the Moon
Today's Conditions |
: | clear sky , Temp -7C down to 2C, ~75% humidity, mediocre seeing, low wind |
For almost all images
Instrument | : | Mak MK67 150/1800mm guided (no Barlow or eyepiece projection) |
Camera | : | QHY5III715C |
Exposure | : | SER Video 2000 frames at 2.2ms/frame | ca 900x900 pixel | size reduced |
Camera Settings | : | @~100 fps, gain 128 |
Software | : | Firecapture, Astrostakkert 3, Astrosurface, Gimp |
![]() |
Rille in the Lunar Alps - First time I got the rille in the rille :-) |
Date - Time : 17 April 2024 - 18:00 UT |
![]() |
Rima Hadley - The site where Apollo 15 landed |
Date - Time : 17 April 2024 - 18:22 UT |
![]() |
Plato crater |
Date - Time : 17 April 2024 - 18:01 UT |
![]() |
Must still find out, what it is ... |
Date - Time : 17 April 2024 - 18:04 UT |
![]() |
Tycho crater - I think ... |
Date - Time : 17 April 2024 - 18:04 UT |
![]() |
The lunar South-Pole region |
Date - Time : 17 April 2024 - 18:05 UT |
![]() |
Another view of the Apennine mountains |
Date - Time : 17 April 2024 - 18:14 UT |
![]() |
Full frame view of the Norther Lunar Hemisphere (reduced size) |
Date - Time : 17 April 2024 - 18:07 UT |
View the full size image : DOWNLOAD HERE |
![]() |
The Moon through the APO refractor. A test image in Black&White with the IMX533C astro camera |
Date - Time : 17 April 2024 - 18:40 UT |
Optics : Omegon Pro AP Triplet ED FCD-100 d=85 f=510mm Apochromat (f=1/6) : Intes MK-67 Maksutov Type Reflector d=150mm f=1800mm (f=1/12) Camera : Omegon veTec 533 C Colour CMOS Camera with IMX533 square 9MP sensor 3,75µm pixels : QHY 5III715C Colour CMOS IMX715 8,2MP sensor 1,45um pixels high speed : NIKON D7000 DSLR unmodified (from 2011) : The Imaging Source DMK21AU4.AS monochrome USB highspeed camera : Panasonic LUMIX G110 MFT System (from 2021) Filter : IR/UV Cut, Astronomik H-Alpha, Astronomik LRGB set + filter drawer add. optics : ED 2x Barlow lens, eyepiece projection : 35mm, 50mm, 135mm and 200mm NIKON lenses available : 2.8/60mm Sigma, 12 .. 60mm Leica for MFT system Mount : VIXEN GP Highspeed Step Motors (Non Vixen Motors) Controller : EQStar Pro (since May 2023) Guiding : PHD2 Aquisition : DELL Notebooks (Windows 10 & Windows 11), SharpCap, FireCapture and others Image Processing : DeepSkyStacker, Siril, Gimp and others latest list update : November 2023
